Grooved Mechanical Cross

Grooved Mechanical Cross
Grooved Mechanical Cross
Product Code : 22
Price And Quantity
  • Minimum Order Quantity
  • 500
  • Unit of Measure
  • Piece/Pieces
Product Description

Our team of highly qualified & experienced workforce helps us in manufacturing and exporting Grooved Mechanical Cross. It is used in fire protection system, feed water system and natural gas system. We manufacture this cross using high quality mild steel at our sound production unit. This cross provides an additional threaded outlet in existing piping. Grooved Mechanical Cross reduces  undesired  angular  movement,  axial  displacement  and  rotation  after  installation  as  is  required  under  normal  service  conditions.

Features:

  • Sturdy in nature
  • Resistant to high impact
  • Easy to fix

Technical Details:

Nominal Size mm/in

Pipe O.D. mm/in

Working

Pressure

PSI/Mpa

Hole Dia mm/in +1.6/+0 063

Dimension mm/in

Bolt Size

Certificate

A

B

C

D

100×65
4×76.1
114.3×76.1
4.500×2.375
362.5
2.5
70
2.75
174
6.58
120
4.724
87
3.425
63
2.48

12×65

UL

100×65
4×76.1
114.3×88.9
4.500×2.375
362.5
2.5
89
3.5
174
6.58
127
5
87
3.425
63
2.48

12×65

UL

150×40
165.1×76.1
165.1×76.1
6.500×3.000
362.5
2.5
70
2.75
229
9.016
120
4.724
125
4.921
90
3.543

12×70

UL

150×80
165.1×3
165.1×88.9
6.500×3.500
362.5
2.5
38
1.5
229
9.016
127
5
125
4.921
90
3.543

12×70

UL

150×100
165.1×4
165.1×114.3
6.500×4.5
362.5
2.5
114
4.5
229
9.016
165
6.496
125
4.921
90
3.543

12×70

UL

200×65
8×76.1
219.1×76.1
8.625×3.000
362.5
2.5
70
2.75
290
11.417
120
4.724
155
6.102
117
4.406

16×85

UL

200×80
8×3
219.1×88.9
8.625×3.500
362.5
2.5
89
3.5
290
11.417
127
5
155
6.102
117
4.406

16×85

UL

200×100
8×3
219.1×114.3
8.625×4.500
362.5
2.5
114
4.5
290
11.417
165
6.496
155
6.102
117
4.406

16×55

UL

250×100
10×76.1
273.0×76.1
10.750×3.000
362.5
2.5
70
2.75
383.7
15.106
117
4.606
117.31
4.619
145.5
5.728

20×120


250×100
10×3
273.0×88.9
10.750×3.500
362.5
2.5
89
3.5
383.7
15.106
122
4.803
178.9
7.043
145.5
5.728

20×120


250×100
10×4
273.0×114.3
10.750×4.500
362.5
2.5
114
4.5
383.7
15.106
154
6.063
178.9
7.043
145.5
5.728

20×120


Trade Information
  • FOB Port
  • Tianjin
  • Payment Terms
  • Western Union, Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C)
  • Supply Ability
  • 10000 pieces Per Month
  • Delivery Time
  • 15 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Sample costs shipping and taxes has to be paid by the buyer
  • Packaging Details
  • carton or plywood
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • UL & FM
